Részletek
Frame Construction: 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated
Fork Construction: 4130 Chromoly, Natch tubing, double-butted tapered fork blades, brazed lugs, ED coated
Rear Dropout Configuration: Forward-exiting horizontal
Rear Hub Spacing: 10 x 135mm
Front Hub Spacing: 10 x 100mm
Rear Brake: Disc - 51mm I.S. (160mm max rotor)
Front Brake: Disc - 51mm I.S. (160mm max rotor)
Head Tube: Ø34mm
Steerer Tube: Ø28.6mm (1-1/8")
Crown Race: Ø30mm (1-1/8")
Stock Headset Upper (S.H.I.S.): EC34/28.6
Stock Headset Lower (S.H.I.S.): EC34/30
Seat Collar: Ø30mm
Seatpost: Ø27.2mm
Front Derailleur (Clamp): Bottom-pull (Ø28.6mm)
Max Chainring (CL): 1x (Road): 50T / 2x (Road): 39/53T
Bottom Bracket: 68mm threaded (1.37" x 24TPI)
Tire Clearance Frame: 700c: 700c x 42mm (with or without fenders)
Tire Clearance Fork: 700c: 700c x 42mm (w/ fenders) / 700c: 29 x 2.0" (w/o fenders)
Rigid Fork Spec: 700c: 400 x 44mm
Bottle Mounts Frame: 2 Standard
Bottle Mounts Fork: N/A
Rack Mounts Frame: Yes (upper and lower threaded)
Rack Mounts Fork: Yes (upper, lower, and mid-blade threaded)
Fender Mounts Frame: Yes
Fender Mounts Fork: Yes
Other Features: Downtube mounted shifter bosses (cable housing stops not included with frameset)
