Részletek
Frame Construction: 100% Surly Chromoly steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
Fork Construction: 4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated
Rear Dropout Configuration: Vertical
Rear Hub Spacing: "Gnot-Boost"138mm, 10 x 135mm or 10 x 141mm
Front Hub Spacing: 10 x 100mm
Rear Brake: Disc - 51mm I.S. (180mm max rotor)
Front Brake: Disc - 51mm I.S. (203mm max rotor)
Headtube: Ø34mm
Steerer Tube: Ø28.6mm
Crown Race: 30mm (1-1/8")
Stock Headset Upper (S.H.I.S): EC34/28.6
Stock Headset Lower (S.H.I.S): EC34/30
Seat Collar: Ø30.0mm
Seatpost: Ø27.2mm
Front Derailleur (Clamp):
High direct mount top-pull (Ø28.6mm)
26mm offset adapter (included) for 135mm rear hub spacing
29mm offset adapter (not included) for 141mm rear hub spacing
Max Chainring (CL) /Clearances vary widely depending on components and configurations/:
- 1x (47CL): 42T / 2x (47CL): 46/36T
Bottom Bracket: 68mm BSA, threaded
Tire Clearance Frame:
- XS-SM frames: 650b x 41mm (with or without fenders)
- MD-XL frames: 700c x 41mm (with or without fenders)
Tire Clearance Fork:
- XS-SM frames: 650b x 47mm (with or without fenders)
- MD-XL frames: 700c x 44mm (with or without fenders)
Bottle Mounts Frame: 2 Standard
Rack Mounts Frame: Yes
Rack Mounts Fork: Fork crown and mid-blade rack mounts and fender mounts
Fender Mounts Frame: Yes
Fender Mounts Fork: Fork crown and mid-blade rack mounts and fender mounts
